Chinese Researchers Tame Conductor Galloping to Fortify Power Grids

In the quest to fortify power grids against the unpredictable forces of nature, researchers have turned their attention to a long-overlooked challenge: conductor galloping. This phenomenon, where transmission lines sway violently under the combined forces of wind and ice, poses a significant threat to grid stability. While most efforts have focused on prevention, a new study published in the journal “IEEE Access” offers a fresh perspective on emergency mitigation strategies.

Zhongbin Lv, a researcher at the State Grid Henan Electric Power Company Electric Power Research Institute in Zhengzhou, China, led a study that delves into the intricacies of emergency anti-galloping cables. The research focuses on a 500 kV quad-bundle conductor system, a common configuration in high-voltage transmission lines. Lv and his team developed a three-dimensional finite element model to analyze how suspension length and substrate curvature affect the electric field distribution around key components.

The findings are promising. By increasing the suspension length beyond 1.0 meters, the team found that the maximum electric field strength could be reduced to below the corona threshold of 20 kV/cm. “This is a critical threshold,” Lv explains. “Exceeding it can lead to corona discharges, which not only waste energy but also contribute to the degradation of the conductor and surrounding hardware.”

Moreover, the study revealed that increasing the substrate edge curvature radius to 2.5 mm could decrease the maximum surface electric field strength by up to 46.8%. “This is a significant reduction,” Lv notes. “It demonstrates the potential of substrate curvature as a design parameter in mitigating electric field-related issues.”

The implications for the energy sector are substantial. Conductor galloping is a well-known issue, but effective emergency mitigation strategies have been scarce. Lv’s research provides a theoretical framework that could guide the development of more robust anti-galloping measures. “Our methodology is generalizable to other transmission voltage levels and conductor configurations,” Lv states. “This means that the principles we’ve established could be applied to a wide range of scenarios.”

The study’s findings could shape future developments in the field, offering a new avenue for enhancing the reliability of high-voltage transmission systems. As the energy sector continues to grapple with the challenges posed by extreme weather events, research like this is invaluable. It not only advances our understanding of conductor galloping but also paves the way for innovative solutions that can safeguard the stability and efficiency of power grids.

Published in the peer-reviewed journal “IEEE Access,” the study represents a significant step forward in the ongoing effort to secure the energy infrastructure against the vagaries of nature. As Lv and his team continue their work, the energy sector watches closely, eager to see how these findings will translate into practical applications that can bolster grid resilience and reliability.
